Additional information
| Outside Dia | 12 |
|---|---|
| Inner Dia | 4.2 |
| Thick | 0.5 |
| Cone Ht | 0.35 |
| Total Ht | 0.85 |
| Thick Ratio | 0.7 |
| Wt per 1000 | 0.39 |
| 15% Def mm | 0.05 |
| 15% Def : Force N | 73 |
| 15% Def : Stress δII N/mm² | 165 |
| 15% Def : Stress δIII N/mm² | 219 |
| 30% Def : mm | 0.11 |
| 30% Def : Force N | 136 |
| 30% Def : Stress δII N/mm² | 361 |
| 30% Def : Stress δIII N/mm² | 423 |
| 45% Def : mm | 0.16 |
| 45% Def : Force N | 191 |
| 45% Def : Stress δII N/mm² | 589 |
| 45% Def : Stress δIII N/mm² | 612 |
| 60% Def : mm | 0.21 |
| 60% Def : Force N | 240 |
| 60% Def : Stress δII N/mm² | 847 |
| 60% Def : Stress δIII N/mm² | 785 |
| 75% Def : mm | 0.26 |
| 75% Def : Force N | 284 |
| 75% Def : Stress δII N/mm² | 1136 |
| 75% Def : Stress δIII N/mm² | 943 |
| 90% Def : mm | 0.32 |
| 90% Def : Force N | 325 |
| 90% Def : Stress δII N/mm² | 1456 |
| 90% Def : Stress δIII N/mm² | 1086 |
